Matrix Converter

• Application
• Pumps, Fans, HVAC, Elevators, Conveyors, Cranes, Regenerative Applications

• Capacity
• 0.75 kW to 630 kW

• Color
• Grey

• Current Waveform
• Sine Wave (due to sinusoidal output)

• Dimension (L*W*H)
• Varies by model; up to 1,900 x 600 x 445 mm

• Material
• Plastic and Metal Housing

• Output Current
• 2.6 A to 820 A (depending on model)

• Output Power
• Up to 630 kW

• Output Type
• 3-Phase AC

• Output Voltage
• Three-phase 380 to 480 V AC

• Product Type
• Yaskawa U1000 Matrix Drive

• Protection
• IP20, NEMA 1, optional IP54

• Size
• Frame sizes: 3, 4, 5, 6, 7, 8, 9 (varies by power rating)

• Weight
• up to 450 kg (varies by frame size)

• Application
• Fans, Pumps, HVAC, Compressors, Conveyors, General Industrial Automation

• Capacity
• Up to 800 HP

• Color
• Grey

• Current Waveform
• Sinusoidal

• Dimension (L*W*H)
• Varies (e.g. 600 x 400 x 380 mm for 110 kW model)

• Material
• Industrial Grade Components

• Output Current
• Up to 900 A

• Output Power
• Up to 600 kW

• Output Type
• 3-Phase AC

• Output Voltage
• 200-240V / 380-480V AC

• Product Type
• Low Harmonic Matrix Drive

• Protection
• IP20 / NEMA 1

• Size
• Varies (see dimensions)

• Weight
• Varies by model (120-450 kg)
